Availability: In Stock
Warranty: 2-Year Limited Warranty
Shipping: Confirmed orders will be shipped within 2 business days from our US warehouse
The Pantera 640-Zoom w/ LRF represents the next generation of thermal optics, blending cutting-edge imaging technology with field-ready precision. Equipped with a 640×512 thermal sensor, 12μm pixel pitch, and ≤20mK NETD sensitivity, this scope delivers crystal-clear detail and superior target detection, even in low-contrast conditions.
Featuring 1.3x–2.5x optical zoom and 8x digital zoom, the Pantera 640-Zoom provides extended versatility for both close and long-range engagements. Its built-in laser range finder (LRF) offers accurate distance measurement up to 1,200 yards, while the integrated ballistic calculator ensures unmatched shot precision. The system’s true circular display with 100mm eye relief provides a comfortable viewing experience, setting a new standard for high-performance thermal scopes.
ModelPantera 480, Pantera 640
ClassificationThermal Imaging Scope
TypeUncooled VOx(vanadium oxide)
Pantera 480 Resolution(pixel)480*360
Pantera 640 Resolution(pixel)640*512
Pixel Size(µm)12*12
NETD≤20mK（0.02℃）
Frame Rate(Hz)50
Pantera 480 Detection Distance(m)1800/2600
Pantera 640 Detection Distance(m)2600/3900
Pantera 480 Objective lens(mm)35/50
Pantera 640 Objective lens(mm)50/75
Pantera 480 Optical Magnification(x)2.1/3.0
Pantera 640 Optical Magnification(x)2.2/3.3
Digital Zoom(x)2/4/6/8
Pantera 480 Field of View (HxV) Horizontal7.1°/5.0°
Pantera 640 Field of View (HxV) Horizontal7.0°/4.7°
Pantera 480 Field of View (HxV) Vertical7.1°/5.0°
Pantera 640 Field of View (HxV) Vertical7.0°/4.7°
Pantera 480 Field of View (HxV) Diagonal10.0°/7.0°
Pantera 640 Field of View (HxV) Diagonal9.9°/6.6°
Eye Relief(mm)100
Diopter Adjustment(D)-5~+3
TypeIPS
Resolution(pixel)800*800
Reticle Style6
Reticle ColorRed/White/Yellow/Green
Scene ModeCity/Rain/Forest
Image modeWT-HOT/BK-HOT/EDGE/RD-HOT/IN-HOT/SKY
Photo Resolution(pixel)1536*1536
Photo Format.JPG
Video Resolution(pixel)768*768
Video Format.mp4
Storage(GB)Micro SD card(Max. 128)
Image EnginePard IREA
LRF detection range(m/yd)1000/1200
Ballistic CalculatorYes
PIPYes
Hot TrackYes
GyroscopeYes
Recoil-activated recordingYes
Loop RecordingYes
E-compassYes
ShutterMechanical Shutter
MicrophoneYes
Firmware UpgradeYes
USB Tpye-CYes
HDMI OutputYes
WiFiYes
Supported AppsPardVision2
Battery TypeLithium Ion 18650*1
Output Voltage(V)3.7
Operating Time(h)≤6
External power supply(V)Type-C
Degree of protectionIP67
Operating Temp(°C/°F)-30 ~ +55 / -22 ~ +131
Recoil Resistance(J)6000
HousingAluminum Alloy
Objective LensAll-glass multi-coated lens
Pantera 480 Product Dimension/with LRF(L * W * H, mm)"Pantera 480-35mm Lens: 352*93*82 Pantera 480-50mm Lens: 364*93*82"
Pantera 640 Product Dimension/with LRF(L * W * H, mm)"Pantera 640-50mm Lens： 364*93*82 Pantera 640-75mm Lens： TBD"
Pantera 480 N.W/pcs(with LRF&battery, g)"Pantera 480-35mm Lens: 622 Pantera 480-50mm Lens: 681.5"
Pantera 640 N.W/pcs(with LRF&battery, g)"Pantera 640-50mm Lens： 681.5 Pantera 640-75mm Lens： TBD"
Versatile Zoom, Tailored to Your Needs
Select from 1.3x or 2.5x optical base magnification to suit different engagement ranges. The 2/4/6/8× digital zoom enhances the ability to observe fine details—giving you the flexibility to adapt instantly in the field.
World's First True Circular Display
This device proudly features the first true circular display ever developed, setting a new global standard in optical design. Combined with an extended 100mm eye relief, it delivers a more immersive, comfortable, and natural viewing experience—perfect for demanding tactical or outdoor use.
Smart Ballistics, Reliable Rangefinding
This system pairs a powerful 1200-yard LRF with a built-in ballistic calculator for instant, intelligent aiming solutions. No guesswork—just real-time shooting data based on distance, bullet weight and so on. Ideal for precision shooters, hunters, and tactical professionals.
